The XACT nv32, is an image intensified night vision system of the highest quality. It delivers exceptional resolution, visibility and crystal clear image in the harshest of environments.
The nv32 has a robust aluminium body, a compact and lightweight design and provides the operator with a wide field of view, as well a a reduced halo effect. It’s monocular design, can be easily operated by one hand, has improved user safety, reduced neck stress and extended usage time. The nv32 also has the option for an adapter to be weapon mounted, plus as external power source connector, for maximised operational effectiveness.
Like the XACT nv33 binocular, the nv32 has an adjustable head tilt shut off system and is operationally proven as the Netherlands Armed Forces Night Vision System.
Weight 210g. Dimensions(WxHxL) 89x63x39mm
Field of view (FOV) ≥ 40° Magnification X1±0.05 Attachment of external magnification system is possible Focus Range is 25 cm to infinity
- Compact and lightweight
- Weapon mountable
- Adjustable head tilt shut off system
Technical detail
- Configuration
- Monocular or Dual Monocular
- Optical Magnification
- X1
- Image Intensifier Tube
- Up to FOM 2300, Auto gated
- Weight
- Under 210g (w/o battery)
- Field of View
- 40°
- Focus Range
- 25cm to infinity
- Eye Relief
- 25mm
- Diopter
- -6 to +2D
- Power Source
- Single 1.5V AA (Alkaline) or external power source
